Specs

Engine

• GX270, 9 HP Honda engine
• 254cc, gasoline, air cooled, 4 stroke, one cylinder
• Manual starter
• 3-year warranty by the manufacturer

Saw head

• Capacity of 24’’ in diameter
• Maximum board width of 18’’
• Last board cutting capacity ⅞” thick
• Cam lock with hydraulic pressure gauge blade tensioner
• Saw head height adjustment and high-quality manual winch
• Large 7 gallons (26 liters) removable lubrification tank
• Welded Heavy-Duty Stainless steel saw head frame
• Large colored lumber scale, details from ¾’’ up to 4’’, designed by Vallee Forestry Equipment to help you work faster
• Automatic blade lubricant system
• Automatic blade brake system
• Automatic engine throttle and saw blade engagement
• Blade size of 144’’ x 1 ¼’’  (1 blade included)
• 18 inches Flywheel
• MXV-890 Drive Belt
• B56 Flywheel Belt

Frame

• Capacity of 13’ maximum board length, onto a 16’ frame
• Solid steel tubing frame 3” x 3’’ x ⅛” completely welded (no joints)
• 2 stainless steel log clamps
• 2 levelers equipped with casters for easy log rotation
• 3 laser-engraved stopper posts
• 6 Stabilizing legs for optimal leveling
• An expended metal platform at the rear of the frame for tool storage

Towing equipment (off road only)

• Single axle off road trailer kit included
• Wheels and tires
• 2000 lb. suspension and axle
• 2-inch drawbar and 3500-lb. safety chain
