Specs
Motor
Bafang Ultra Drive 1000W torque sensing motor
Brakes
Extreme Duty Tektro HD-E740 4 piston 203/180 hydraulic with electric safety cutoff and special noise reduction pad
Rims
Extreme Strength Double Wall Aluminum Alloy to prevent rim damage during off-road and rough trail terrain
Gear System
SRAM High-End NX 11 speed with 420% range.
Performance
1632 peak rating, 160Nm of torque, 1000w nominal power.
Tires
All Terrain Maxxis Minion 26 x 4.0 Aggressive Tread Tire with Anti Puncture Technology
UPGRADE: Tannus Armor—Don’t live in fear of flat tires. Tannus Armous is proven to eliminate 90% of all punctures by providing a layer of protection between the tube and the ground.
Chain
KMC Branded X9e. Specially made for high-performance E-Bike power.
Battery
48v 20ah 720WH with LG branded cells
UPGRADE: 30 ah R127-30 battery—Take your travel to the next level. Increase your total range by up to 65 miles using Pedal Assist or 32 miles with throttle only.
Seat
UPGRADE: Cloud 9 Airflow Saddle Seat—Ultra wide, thick padding and built for extra-long rides across trails or tough terrain, this seat is the top recommendation from hunters.
UPGRADE: Cloud 9 Sport—Designed with memory foam comfort and to keep you in pursuit of your passion longer than ever before.
Pedals
Extra wide Wellgo aluminum alloy
UPGRADE: Extra Wide pedals equipped with gripping traction pins to keep your feet in place as you tackle the toughest terrain. Snow, mud, and rocky ground are no match for these pedals.
Range
Up to 65 miles on the standard battery, up to 98 miles using the 30AH upgrade.
Throttle
Powered by the push of your thumb on the right side throttle
Weight
68lbs. with battery removed. Battery weight 11lbs.
Speed
Up to 32mph.
Frame
Hydroformed aluminum alloy 6061 T6 heat treated, tig welded to the highest specifications
Display
Featuring Adjustable Class System (ACS) and waterproof
Load Capacity
350 lbs.
Model
Dominator UD
Drive Type
Mid-Drive
