Specs
engine 7
Engine Model
KIOTI 1.2L 3 Cylinder
Engine Manufacturer
KIOTI
Engine Power
24.50 hp (18.30 kW)
Engine Displacement
72.20 cu. in. (1,233 cc)
RPM
Fuel Type
Diesel
Fuel Capacity
17.20 gal (65 L)
Drive Train 8
Drive Train Model
2HST
Drive Train Pump Displacement
Drive Train Pump Displacement
Clutch Torque
Charging System
Brakes
Foot Pedal
Travel Speed Min.
11 mph (17.70 km/h)
Travel Speed Max.
11 mph (17.70 km/h)
deck 11
Deck Type
Fabricated Steel
Lift Mechanism
Foot Pedal
Deck Steel Thickness
7 Gauge
Front Anti-Scalp Ball Rollers
4
Rear Anti-Scalp Ball Rollers
2
Cutting Width
72 in (1,829 mm)
Blade Types
Notched
Cutting Height Min.
1 in (25 mm)
Cutting Height Max.
5 in (127 mm)
Discharge Chute
Side Discharge
Height Adjustment
Dial Type
dimensions 6
Length
91.70 in (2,328 mm)
Height Max
82.40 in (2,092 mm)
Wheelbase Width
59.40 in (1,510 mm)
Width
59.60 in (1,515 mm)
Weight
1,980 lb (898 kg)
Height
82.40 in (2,092 mm)
