Specs
Engine 8
Model
4F243T
Engine Manufacturer
KIOTI
Power
73 hp (54.40 kW)
Displacement
148.60 cu. in. (2,435 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Turbo Charged
Fuel Capacity
25 gal (95 L)
Transmission 8
Transmission
Manual: Power Shuttle
Shuttle
Power Shuttle
Travel Speeds Forward
12
Travel Speeds Reverse
12
Travel Speeds Minimum Speed
1.01 mph (1.63 km/h)
Travel Speeds Maximum Speed
23.53 mph (37.86 km/h)
Travel Speeds Min Reverse Speed
1 mph (1.61 km/h)
Travel Speeds Max Reverse Speed
37.23 mph (23.13 km/h)
PTO 4
PTO Type
Independent
PTO Power
63 hp (47 kW)
Rear Speed
540 rpm
Mid Speed
N/A
Drive Train 3
Brakes
Wet Multi Disc
Clutch
Wet Disc
Steering
Mechanical
Hydraulics 3
Pump
Gear
Pump Capacity
19.20 gpm (72.80 lpm)
Lift Capacity
3,898 lb (1,768 kg)
Hitch 4
Type
Three Point
Category
Category 2
Control Type
Position, Draft, Mixed Control
Lift Capacity
2,716 lb (1,232 kg)
dimensions 9
Length with Hitch
146.30 in (3,715 mm)
Width
77.20 in (1,960 mm)
Height
104.50 in (2,655 mm)
Wheelbase
83.90 in (2,130 mm)
Ground Clearance
17.30 in (440 mm)
Front Tread
58.10 in (1,465 mm)
Rear Tread
59.60 in (1,515 mm)
Turning Radius
11.20 ft (3.40 m)
Weight
6,162 lb (2,795 kg)
