Specs
Engine 8
Model
3F183T
Engine Manufacturer
KIOTI
Power
45 hp (33.60 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Turbo Charged
Fuel Capacity
14.80 gal (56 L)
Transmission 8
Transmission
Hydrostatic
Shuttle
Synchronized
Travel Speeds Forward
16
Travel Speeds Reverse
16
Travel Speeds Minimum Speed
16.52 mph (26.59 km/h)
Travel Speeds Maximum Speed
16.52 mph (26.59 km/h)
Travel Speeds Min Reverse Speed
16.52 mph (26.59 km/h)
Travel Speeds Max Reverse Speed
16.52 mph (26.59 km/h)
PTO 4
PTO Type
Independent
PTO Power
33.90 hp (25.30 kW)
Rear Speed
540 rpm
Mid Speed
2,000 rpm (Optional)
Drive Train 3
Brakes
Wet Multi Disc
Clutch
None
Steering
Hydrostatic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
17.90 gpm (67.60 lpm)
Lift Capacity
3,177 lb (1,441 kg)
Hitch 4
Type
Three Point
Category
Category 1
Control Type
Position with Draft Control
Lift Capacity
3,177 lb (1,441 kg)
dimensions 9
Length with Hitch
139.60 in (3,547 mm)
Width
65.60 in (1,665 mm)
Wheelbase
75.60 in (1,920 mm)
Ground Clearance
13.70 in (350 mm)
Front Tread
55.20 in (1,352 mm)
Rear Tread
52.10 in (1,324 mm)
Turning Radius
9.81 ft (2.99 m)
Weight
4,000 lb (1,814.40 kg)
Height
103.10 in (2,618 mm)
