Specs
Engine 7
Model
3A165LWH-U2
Engine Manufacturer
KIOTI
Power
24.50 hp (18.30 kW)
Displacement
87 cu. in. (1,647 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Fuel Capacity
6.60 gal (25 L)
Transmission 9
Transmission
Manual
Shuttle
Manual
Main Gear
Manual
Travel Speeds Forward
10
Travel Speeds Reverse
4
Travel Speeds Minimum Speed
0.75 mph (1.22 km/h)
Travel Speeds Maximum Speed
10.80 mph (19.07 km/h)
Travel Speeds Min Reverse Speed
0.92 mph (1.51 km/h)
Travel Speeds Max Reverse Speed
4.20 mph (7.40 km/h)
PTO 4
PTO Type
Transmission
PTO Power
19.30 hp (14.40 kW)
Rear Speed
540 rpm
Mid Speed
2,000 rpm
Drive Train 3
Brakes
Wet Disc Type
Clutch
Dry Single Stage
Steering
Hydraulic Power Steering
Hydraulics 3
Pump
Gear
Pump Capacity
11.30 gpm (42.90 lpm)
Lift Capacity
1,203 lb (546 kg)
Hitch 4
Type
Three Point
Category
Category 1
Control Type
Position
Lift Capacity
1,203 lb (546 kg)
dimensions 9
Length with Hitch
109.08 in (2,790 mm)
Width
49.40 in (1,256 mm)
Wheelbase
59.80 in (1,520 mm)
Ground Clearance
13.40 in (340 mm)
Front Tread
38.10 in (968 mm)
Rear Tread
37.40 in (951 mm)
Turning Radius
9 ft (2.75 m)
Weight
2,308 lb (1,047 kg)
Height
82.80 in (2,103 mm)
