Specs
Engine 8
Model
3H-TM4A
Engine Manufacturer
KIOTI
Power
39.60 hp (29.50 kW)
Displacement
111.40 cu. in. (1,826 cc)
RPM
2,600 rpm
Fuel Type
Diesel
Aspiration
Intercular
Fuel Capacity
9 gal (34 L)
Transmission 9
Transmission
Hydrostatic
Shuttle
None
Main Gear
Hydrostatic
Travel Speeds Forward
23
Travel Speeds Reverse
16
Travel Speeds Minimum Speed
0 mph (0 km/h)
Travel Speeds Maximum Speed
14.88 mph (23.94 km/h)
Travel Speeds Min Reverse Speed
0 mph (0 km/h)
Travel Speeds Max Reverse Speed
10.41 mph (16.76 km/h)
PTO 4
PTO Type
Live
PTO Power
33.30 hp (24.80 kW)
Rear Speed
540 rpm
Mid Speed
2,000 rpm (Optional)
Drive Train 3
Brakes
Wet Multi Disc
Clutch
Dry Single Plate
Steering
Mechanical
Hydraulics 3
Pump
Gear
Pump Capacity
11.70 gpm (44.40 lpm)
Lift Capacity
1,631 lb (740 kg)
Hitch 4
Type
Three Point
Category
Category 1
Control Type
Position
Lift Capacity
1,631 lb (740 kg)
dimensions 9
Length with Hitch
120.90 in (3,070 mm)
Width
54.50 in (1,385 mm)
Height
92.90 in (2,360 mm)
Wheelbase
65.70 in (1,670 mm)
Ground Clearance
13.40 in (340 mm)
Front Tread
48.20 in (1,225 mm)
Rear Tread
47.60 in (1,210 mm)
Turning Radius
8.96 ft (2.73 m)
Weight
2,734 lb (1,240 kg)
