Specs
| Chipping | |
|---|---|
| Chipper Knife Material | Heat Treated D2 Tool Steel |
| Chipper Knife Size | 7-1/4 x 1-1/4 x 9/32" |
| Chipper Knife Speed | 144 MPH (40 Bites Per Second) |
| Chipping Capacity | 5-3/4" Diameter |
| Hopper Opening Size | 19 x 30.5 |
| Dimensions | |
|---|---|
| Flywheel | 20" Diameter x 5/8" Thick |
| Flywheel Weight | 62.5 lbs |
| Height | 58.25" |
| Length | 66" Tongue up / 86" Tongue down |
| Engine | |
|---|---|
| Air Filter | Dual-Element |
| Displacement | 420cc |
| Engine Type | OHV |
| Ft Lbs Torque | 19.60 |
| Horsepower | 12 |
| Lubrication | Splash |
| Make | DR |
| Number Of Cylinders | 1 (w/ Cast-Iron Sleeve) |
| Oil Capacity | 1.2 Quarts |
| Oil Type | SAE 30W HD |
| RPM Speeds | 3600 rpm |
| Starting Type | Electric w/ Manual Back Up |
| Fuel_System | |
|---|---|
| Fuel Capacity | 1.7 Gallons |
| General | |
|---|---|
| Assembly | Yes |
| Wheels_Tires | |
|---|---|
| Tire Size | 4.10/3.50-6 12" / 4.80/4.00-8 14" |
| Warranty | |
|---|---|
| Engine Warranty | 2 Year Residential, 1 yr Commercial |
| Machine Warranty | 2 Year Residential, 90 Day Commercial |
