Specs
| Chipping | |
|---|---|
| Chipper Flywheel | 17.75" Diameter x 5/8" Thick |
| Chipper Knife Size | 6-1/4 x 1-1/4 x 9/32" |
| Chipper Knife Speed | 128 MPH (40 Bites Per Second) |
| Chipping Capacity | 4-3/4" Diameter |
| Hopper Opening Size | 17 x 27 |
| Engine | |
|---|---|
| Air Filter | Dual-Element |
| Displacement | 389cc |
| Engine Type | OHV |
| Ft Lbs Torque | 18.40 |
| Horsepower | 11.7 |
| Lubrication | Splash |
| Make | DR |
| Number Of Cylinders | 1 (w/ Cast-Iron Sleeve) |
| Oil Capacity | 1.2 Quarts |
| Oil Type | SAE 30W HD |
| Starting Type | Electric w/ Manual Back Up |
| Dimensions | |
|---|---|
| Height | 50.5" |
| Length | 59" Tongue up / 79" Tongue down |
| Weight | 270 lbs |
| Fuel_System | |
|---|---|
| Fuel Capacity | 1.7 gallons |
| Wheels_Tires | |
|---|---|
| Number of Tires | 2 |
| Tire Size | 4.10/3.50-6 12" |
| Tread | Saw-tooth |
| Warranty | |
|---|---|
| Engine Warranty | 2 yrs residential use, 1 yr commercial |
| Machine Warranty | 2 yrs residential use, 90 day commercial |
