Altoz TSX

Contact us for price

Stock status: Call Store for Availability

World’s first tracked stand-on mower, the TSX offers the ability to get more done in less time with an unmatched degree of stability on slopes, maneuverability and precision.

Call Us Now

Specs

TSX 561 i

Engine

  • Horsepower : 29.5
  • Manufacturer : Kawasaki
  • Model : FX EFI
  • Displacement (cc) : 852
  • Cylinders : 2
  • Air Filter : Multi-Stage Canister
  • Fuel : Gasoline
  • Fuel Vol (gal) : 8.5
  • Fuel Tank Location : RH Side, Single

Drive Line

  • Trans Type : Hydrostatic
  • Trans Manufacturer : Parker/Hydro-Gear
  • Trans Model : Parker TF 195cc Wheel Motors/Hydro-Gear PR 16cc Pumps
  • Max Forward Speed : Up to 10 mph
  • Front Tire Size : 13″
  • Rear Track Size : 11″ x 74″ Track

Features

  • TorqFlex™ Front Suspension
  • Torsion Axle Rear Suspension
  • Fully Adjustable Coil Spring Over Gas Shock Rider Platform
  • Ergonomically Adjustable Hand Controls
  • Electric Dial Throttle
  • Soft Start Clutch Engagement
  • Keyless Push‑to‑Start
  • SmarTrac Pro Control

Dimension / Weight

  • Length : 75″
  • Width (Chute Up) : 62.5″
  • Weight : 1450 lbs
  • Height : 50″

Cutting Deck

  • Cutting Width : 61″
  • Deck Type : Fabricated Steel HV All-Terrain Deck or Aero Deck
  • Deck Thickness : Laminated 7 and 7 Gauge (AT), Laminated 10 and 7 Gauge (FC)
  • Deck Depth : 6″ (AT) / 5.5″ (FC)
  • Cut Height (Min – Max) : 2.5″ – 5.5″ (AT) / 2.5″ – 6″ (FC)
  • Cutting Height Steps : 1/4″ Increments
  • Number of Blades : 3
  • Blade Speed : 17,250 fpm
  • Anti-Scalp Wheels : n/a
  • Deck Lifting System : Manual
  • Clutch Torque : 250 ft-lbs
  • Clutch Mfr : Warner

Warranty

  • Homeowner / Commercial : 3 year engine / 2 year transmission / 1 year manufacturer
  • Rental : n/a
